UAED on TBM: Original vs Super-Resolution

This repository is the project page for the paper
“Evaluating Diffusion-based Super-Resolution for Trustworthy Quantitative Metallography”,
published at the NeurIPS 2025 AI4Mat workshop.

Overview

Recent advances in generative based super resolution(SR)has set SOTA performance on natural images upsampling. Super-resolution holds promise for improving metallographic analysis, but diffusion-based methods raise concerns about hallucinated structures that could bias quantitative results. We present the first systematic study of diffusion SR in quantitative metallography. Using OSEDiff with a fixed domain prompt (“metallographic image”), we generate a fourfold super-resolved version of the Texture Boundary in Metallography (TBM) dataste(SR-TBM) and train edge detectors on both original and SR images. We evaluate both pixel based edge detection metrics, and global grain size estimation (Heyn Intercpet). We demonstrate generative AI, under domain specific constraints, can be used to dramatically improve metallographic images quality. A human expert audit found virtually no major hallucinations. Models trained on SR-TBM achieved a comparable pixel-based performance, while demonstrating a 47% reduction in grain-size error.

Talk video

Code and data

Edge detection for metallography on the TBM dataset. Two tracks: training and evaluating UAED on the original TBM images and on a super-resolved variant (SR_TBM).

Pretrained checkpoints and datasets download available on: https://zenodo.org/records/16918388

Repository layout

.
├── checkpoints/
│   ├── uaed_tbm.pth          # trained on TBM_original
│   └── uaed_sr_tbm.pth       # trained on SR_TBM
├── scripts/
│   ├── train.py              # training entry point
│   ├── eval_on_folder.py     # evaluation on an images+masks folder
│   ├── train_original/repro.sh
│   ├── train_sr/repro.sh
│   ├── eval_original_configs/run_command.txt
│   └── eval_sr_configs/run_command.txt
├── TBM_original/             # original-resolution dataset
│   ├── train/{images,images_1024,masks}
│   ├── val/{images,images_1024,masks}
│   └── test/{images,images_1024,masks}
└── SR_TBM/                   # super-resolved dataset
    ├── train/{images,masks}
    ├── val/{images,masks}
    └── test/{images,masks}

Notes

• images_1024/ are linearly upscaled originals for parity with SR inputs.
• Filenames in images/ and masks/ are one-to-one.

Environment

Runs under the UAED environment. Follow the setup from the UAED repository and keep the same Python/CUDA stack.

• UAED GitHub: https://github.com/ZhouCX117/UAED_MuGE

Minimal extras commonly used here (install after the UAED setup):

pip install numpy pandas scikit-image imageio matplotlib tqdm

Quick start

Evaluate the provided checkpoints

Original TBM

python scripts/eval_on_folder.py   --images TBM_original/test/images_1024   --masks  TBM_original/test/masks   --ckpt   checkpoints/uaed_tbm.pth   --out    outputs/tbm_eval
# Or replicate our exact command(s):
cat scripts/eval_original_configs/run_command.txt

SR_TBM

python scripts/eval_on_folder.py   --images SR_TBM/test/images   --masks  SR_TBM/test/masks   --ckpt   checkpoints/uaed_sr_tbm.pth   --out    outputs/sr_tbm_eval
# Or:
cat scripts/eval_sr_configs/run_command.txt

Help

python scripts/eval_on_folder.py -h

Expected outputs

• Probability maps, uncertainty maps, thresholded masks, and overlays.
• CSV report with AP, ROC-AUC, thresholded metrics, and a pooled Heyn grain-size estimate.
• PR/ROC curve images.

Train from scratch

Original TBM

bash scripts/train_original/repro.sh

SR_TBM

bash scripts/train_sr/repro.sh

Direct help

python scripts/train.py -h

Outputs

• Checkpoints saved under checkpoints/ (or a run directory if configured).
• Validation figures similar to eval.
• Optional logs/TensorBoard if enabled in the scripts.

Data

Folder convention:

DATA_ROOT/{train,val,test}/images/*.png
DATA_ROOT/{train,val,test}/masks/*.png
# TBM_original also has {train,val,test}/images_1024/*.png

Masks are single-channel PNGs (0/255 or 0/1). Filenames match between images/ and masks/.

Checkpoints

• checkpoints/uaed_tbm.pth — UAED trained on TBM_original.
• checkpoints/uaed_sr_tbm.pth — UAED trained on SR_TBM.

Use --ckpt in eval_on_folder.py or the training script to select a model.

Reproducibility

• Use the exact commands in:
  • scripts/train_original/repro.sh
  • scripts/train_sr/repro.sh
  • scripts/eval_*_configs/run_command.txt
• Fix seeds and keep hardware/software constant when possible.

Acknowledgments

• UAED for the uncertainty-aware edge detection framework and training codebase. https://github.com/ZhouCX117/UAED_MuGE
• OSEDiff for one-step effective diffusion SR used to produce SR_TBM. https://github.com/cswry/OSEDiff

Citation

If this repository helps your work, please cite our accompanying paper(s) and the upstream projects UAED and OSEDiff.

License

Apache-2.0

Contact

Open an issue or pull request with a minimal reproducible example.
